Air Compressor
TE-AC 430/90/10
Item no.:4010800EAN: 4006825642339
einhell-expert-air-compressor-4010800-productimage-001
einhell-expert-air-compressor-4010800-example_usage-001
einhell-expert-air-compressor-4010800-detail_image-001
einhell-expert-air-compressor-4010800-detail_image-002
einhell-expert-air-compressor-4010800-detail_image-003
einhell-expert-air-compressor-4010800-detail_image-004
einhell-expert-air-compressor-4010800-detail_image-005
einhell-expert-air-compressor-4010800-detail_image-006
einhell-expert-air-compressor-4010800-productimage-001
einhell-expert-air-compressor-4010800-example_usage-001
einhell-expert-air-compressor-4010800-detail_image-001
einhell-expert-air-compressor-4010800-detail_image-002
einhell-expert-air-compressor-4010800-detail_image-003
einhell-expert-air-compressor-4010800-detail_image-004
einhell-expert-air-compressor-4010800-detail_image-005
einhell-expert-air-compressor-4010800-detail_image-006
Air Compressor

TE-AC 430/90/10

Item no.: 4010800 EAN: 4006825642339
  • High-performance compressor with V-belt drive
  • Belt drive ensures low speed and quiet operation
  • Long life thanks to oil lubricated pump & high quality components
  • Oil level check through a window
  • The 90 l tank provides sufficient air reserves for prolonged jobs
  • High air flow & long durability thanks to double compressor unit
  • Applications up to 10 bar can be set using the pressure reducer
  • Pressure gauge & quick-release coupling for regulated pressure
  • Pressure gauge & quick-release coupling for unregulated pressure
  • 2 large wheels and 2 castors with one locking brake
  • 10 years warranty against rusting through of the tank
  • Non-return valve, safety valve
  • The drain plug enables user-friendly maintenance
See more information
Show less information
einhell-expert-air-compressor-4010800-productimage-001
Article description

With the Einhell compressor TE-AC 430/90/10 and the right tools to go with it, you can apply lacquer and paint in next to no time and apply preservative oil to small or large surfaces on wood. The high-performance compressor with V-belt drive and 3,000 W (4.1 HP) makes it possible to use a whole range of new tools, the belt drive ensures a low speed and smooth operation, and the 90 l tank provides plenty of air reserves for prolonged jobs. Many applications up to a maximum of 10 bar, including blow-cleaning or sand-blasting jobs, can be set by the pressure reducer. This allround helper also effortlessly inflates car, motorbike and cycle tires, as well as balls and air mattresses. The double compressor unit and the V-belt drive assure a high output power. The oil lubrication of the pump and high quality components contribute to a long life for the compressor. The oil level can be checked through a window. Safety during operation is ensured by the non-return and safety valve. There is an integrated pressure gauge and a quick-release coupling for regulated working pressure and unregulated tank pressure. Einhell is convinced of the quality and provides a ten year rust-through warranty for the tank. For mobility and a secure holding position there are two large wheels and two castors with one locking brake. The drain plug on the compressor enables user-friendly maintenance.

See more information
Show less information

Technical details

Max. operating pressure10 bar
Motor speed2850 min^-1
Number of cylinders2 pcs
Output power 0 bar230 l/min
Output power 4 bar210 l/min
Output power 7 bar200 l/min
Product weight68.35 Kg
Pump speed1020 min^-1
Sound pressure level (volume)73 dB (A)
Suction power430 l/min
Tank volume90 l
Sufficient-air-reserves

Sufficient air reserves

With its 90-litre tank, the compressor is suitable for various compressed air applications up to a maximum pressure of 10 bar.

Convenient-maintenance

Convenient maintenance

The condensate produced by the overpressure in the boiler can be emptied with the drainage screw on the underside.

Oil-lubricated-pump

Oil-lubricated pump

Thanks to high-quality components and the oil-lubricated pump, a long service life is guaranteed. The oil level is checked via a sight glass.

Simple-transport

Simple transport

Two large wheels and two swivel castors with a parking brake ensure mobility and a secure holding position.

Quiet-operation-by-V-belt-drive

Quiet operation by V-belt drive

A whole new class of tools can be opened up with the 3,000 W (4.1 hp) powerful and robust compressor with V-belt drive. The belt drive ensures a low engine speed of 2850 rpm and thus ensures smooth operation.

Regulated-working-pressure

Regulated working pressure

For regulated working pressure adapted to each application, a pressure gauge and a quick coupling are available for the connection of the right accessories. At an operating pressure of 7 bar, the compressor has a maximum output of 200 litres per minute.

So you'll never run out of air!

The Einhell compressor TE-AC 430/90/10 can not only easily inflate car, motorcycle & bicycle tyres, or balls and air mattresses, but is also used for blowing and sandblasting work. Various suitable compressed air tools from Einhell are available separately.
